Japan Column

August 17, 2010 (Last update: Jan. 21, 2011)
JSM 7th Annual Conference at Omaezaki, Shizuoka

Day Three (July 15, 2010)

[A-4] Seismic Safety

Chair: Takashi ITO (Hitachi-GE) and Tomoya MATSUNAGA (Kansai Electric Power)

A-4-1
Evaluation of Soundness for Circulating Water Pipes

Yoshihiro KUNITOMO, Tsuyoshi HIRATA and Tetsuo TERAMAE (The Tokyo Electric Power Co., Inc.)

Abstract
After Niigata-ken Chuetsu-Oki Earthquake happened, some deformations were found at buried parts of circulating water pipes at Kashiwazaki-Kariwa Nuclear Power Plants. We had evaluated the soundness of deformed pipes, and concluded that the degree of deformations is small enough to use these pipes continuously. In this paper, some results of these evaluations are described.

Keywords
Niigata-ken Chuetsu-Oki Earthquake, Circulating water pipe, Deformation, Evaluation of soundness


A-4-2
Evaluation of Cylindrical Tank Sloshing

Kunihiro NISHIOKA (The Tokyo Electric Power Co., Inc.), Kiyoshi HATTORI, Masahiko WARASHINA, Ryoji YOSHIMURA (TOSHIBA CORPORATION), Naoki FUKUSHI (Hitachi-GE Nuclear Energy, Ltd.)

Abstract
For tank, the evaluation method for influence about top board by fluid sloshing is not defined well. We carried out shaking test about cylindrical tank to investigate behavior of inner fluid. And we conducted simulation analyses about the shaking test, too. In this paper, results of the shaking test and simulation analyses, and evaluation for comparison of those are described.

Keywords
Cylindrical tank, Sloshing, Earthquake, Shaking test, Simulation analyses, Nuclear power plant


A-4-3

Maintenance Program After Earthquake (Reaction to earthquake in Suruga Bay)

Yoshiki FURUTANI (CHUBU Electric Power Co., lnc.)

Abstract
On August 11th, 2009, an earthquake in Suruga Bay resulted in automatic shutdown of unit 4 and 5 at Hamaoka Nuclear Power Station. Based on in-house procedures for restart, a special maintenance program was developed and executed. This paper describes an outline of this program, detailed inspection items and insights though the results of inspections

Keywords
Earthquake, Maintenance Program, Observation Records, Seismic Design Class


A-4-4

Maintenance Report of Hamaoka Nuclear Power Station Reactor No. 5 Turbine Damaged by Suruga Bay Earthquake

Yoshirou HASEGAWA, Kazuaki HORII (CHUBU Electric Power Co., lnc.), Kaoru AOKI and Naoaki SHIBASHITA (Hitachi, Ltd.)

Abstract
Hamaoka Nuclear Power Station Reactor No. 5 was automatically shut down when an earthquake occurred in Suruga Bay on August 11, 2009. A special maintenance plan for inspections to verify the soundness of equipment and facilities in Hamaoka Nuclear Power Station was formulated following the earthquake. The main steam turbine in Hamaoka Nuclear Power Station Reactor No. 5 was inspected based on the plan. The middle standard bearing box, which had the thrust bearing of the turbine was found to lift slightly from the turbine base. Deformation of the fixing bolts and keys of the middle standard bearing box was also observed. The phenomena indicated that the turbine rotor remarkably moved along the axial direction relatively to the stationary blades due to the earthquake. In this paper, the results of the inspections conducted on the turbine in Hamaoka Nuclear Power Station Reactor No. 5, especially repair and restoration of the middle standard bearing box are described.

Keywords
steam turbine, earthquake, special maintenance plan, middle standard bearing box, thrust bearing


A-4-5


Seismic safety evaluation of piping system with local wall thinning by LDI (Part1) - Thinning Management of piping system in Hamaoka Power Station -

Shigenobu ONISHI, Mitsuo KUGIMOTO (CHUBU Electric Power Co., lnc.), Michiya SAKAI, Ryo MORITA, Ryo MORITA, Shin-ichi MATSUURA and Fumio INADA (Central Research Institute of Electric)

Abstract
In Hamaoka Power Station, thinning management of piping system is considering earthquake resistance. Current management method is too conservative due to assumption that has large range thinning by liquid droplet impingement erosion (LDI). Therefore, we are developing reasonable earthquake safety evaluation method suited for locally-thinning caused by LDI. To understand the influence on earthquake resistance by the locally-thinning, fixed quantity evaluation was executed based on an actual thinning case.

Keywords
Liquid Droplet Impingement Erosion (LDI), Seismic safety evaluation, Thinning Management


A-4-6

Seismic safety evaluation of piping system with local wall thinning by LDI (Part 2) - Evaluation of local thinning shape by LDI -

Ryo MORITA, Michiya SAKAI (Central Research Institute of Electric), Shigenobu ONISHI, Mitsuo KUGIMOTO (CHUBU Electric Power Co., lnc.), Fumio INADA and Shin-ichi MATSUURA (Central Research Institute of Electric)

Abstract
For seismic safety of piping system with local thinning surface by liquid droplet impingement erosion (LDI), hybrid tests were conducted to the piping with locally-thinned elbow. In this presentation, determination method of the thinning shape on the elbow is developed.

To determine the thinning shape by LDI, droplet behavior at the elbow is calculated in various flow and piping size conditions, and collision point and velocity for each droplet is evaluated. Then, the relationship between collision conditions and thinning rate is assumed from existing knowledge and thinning shape is determined. The evaluated thinning shape is compared with actual LDI case for the validation of the method, and the method is confirmed.

Keywords
Liquid Droplet Impingement Erosion (LDI), Thinning Shape, Droplet Behavior


A-4-7


Seismic safety evaluation of piping systems with locally wall thinning by LDI (Part3) - Seismic performance effects of elbow pipes by loading tests -

Michiya SAKAI, Shinichi MATSUURA, Ryo MORITA, Fumio INADA (Central Research Institute of Electric), Shigenobu ONISHI and Mitsuo KUGIMOTO (CHUBU Electric Power Co., lnc.)

Abstract
In order to evaluate seismic safety of piping systems with locally wall thinning by LDI, hybrid tests have been conducted incorporating a numerical analysis of whole system with a loading test of elbow model. Seismic performance effects of wall thinning elbow were clarified by comparing three cases of different thickness elbow models such as no defect, 50% thinning and 75% thinning. By these results, the almost same hystereses of the non-linear load displacement relations were obtained and the damages of elbow specimen were not found out by penetrate tests. The static finite element analyses under cyclic loadings were also carried out to consider above results.

Keywords
Liquid Droplet Impingement Erosion (LDI), Wall Thinning, Seismic Evaluation, Hybrid Testing


EJAMJP2_JSM7thAnnualConference_A-4

Fig. 14 A discussion after a presentation on [A-4] "Seismic Safety"

Reference:
Proceedings of JSM 7th Annual Conference, p.341-p.369, Omaezaki, July 2010 (in Japanese).
